External electric heating coil. Available with round or rectangular connection to match our range of compact VEX units.
See references
HE electric heating coil
External electric heating coil. Available with round or rectangular connection to match our range of compact VEX units.
HE electric heating coil

Product advantages

  • External reheat coil for electrical connection
  • Increases the temperature of the supply air
  • Can be controlled via EXact/EXact2 or via other automation
  • Delivered in uninsulated cabinet
References Modulating steps
HCE240HK162

1
HCE240HK6X2

1
HCE250HK1122

1
HCE250HK12X2

1
HCE260HK1142

1
HCE260HK14X2

1
HCE270HK1212

1
HCE270HK212

1
HCE270HK21X2

1
HCE280HK146

1
HCE280HK146D

1
HCE280HK46X

1
HCE280HK46XD

1
HCE340HK6X
HCE500X800U15
HCE500X800U15X
HCE500X800U15XN
HCE500X800U24
HCE500X800U24X
HCE500X800U9
HCE500X800U9X
HE05X0809BUE

1
HE05X0809BUX

1
HE05X0815BUE

1
HE05X0815BUX

1
HE05X0824BUE

1
HE05X0824BUX

1
HE31504BUE

1
HE31504BUX

1
HE31504CUE

1
HE31504CUX

1
HE31508BUE

1
HE31508BUX

1
HE31508CUE

1
HE31508CUX

1
HE40006BUE
HE40006BUX
HE40012BUI
PHCE2502EXC
PHCE3156
PHCE3156EXC
PHCE3159
PHCE340HK12
PHCE40012
PHCE4006
PHCE4009EXC
PHCE50015
PHCE5006
PHE12020
PHE2412
PHE3612
PHE4812
PHE4820
PHE6312
PHE7220
PHE7512
PHE9620
PHCE340HK9N
References Weight (kg)
HCE240HK162

19
HCE240HK6X2

19
HCE250HK1122

29
HCE250HK12X2

29
HCE260HK1142

35
HCE260HK14X2

35
HCE270HK1212

45
HCE270HK212

45
HCE270HK21X2

45
HCE280HK146

68
HCE280HK146D

68
HCE280HK46X

68
HCE280HK46XD

68
HCE340HK6X
HCE500X800U15
HCE500X800U15X
HCE500X800U15XN
HCE500X800U24
HCE500X800U24X
HCE500X800U9
HCE500X800U9X
HE05X0809BUE

34
HE05X0809BUX

34
HE05X0815BUE

36
HE05X0815BUX

36
HE05X0824BUE

42
HE05X0824BUX

42
HE31504BUE

19
HE31504BUX

19
HE31504CUE

19
HE31504CUX

19
HE31508BUE

19
HE31508BUX

19
HE31508CUE

19
HE31508CUX

19
HE40006BUE
HE40006BUX
HE40012BUI
PHCE2502EXC
PHCE3156
PHCE3156EXC
PHCE3159
PHCE340HK12
PHCE40012
PHCE4006
PHCE4009EXC
PHCE50015
PHCE5006
PHE12020
PHE2412
PHE3612
PHE4812
PHE4820
PHE6312
PHE7220
PHE7512
PHE9620
PHCE340HK9N
References Minimum airflow
HCE240HK162

290
HCE240HK6X2

290
HCE250HK1122

290
HCE250HK12X2

290
HCE260HK1142

580
HCE260HK14X2

580
HCE270HK1212

900
HCE270HK212

900
HCE270HK21X2

900
HCE280HK146

1520
HCE280HK146D

1520
HCE280HK46X

1520
HCE280HK46XD

1520
HCE340HK6X
HCE500X800U15
HCE500X800U15X
HCE500X800U15XN
HCE500X800U24
HCE500X800U24X
HCE500X800U9
HCE500X800U9X
HE05X0809BUE

720
HE05X0809BUX

720
HE05X0815BUE

720
HE05X0815BUX

720
HE05X0824BUE

720
HE05X0824BUX

720
HE31504BUE

290
HE31504BUX

290
HE31504CUE

290
HE31504CUX

290
HE31508BUE

290
HE31508BUX

290
HE31508CUE

290
HE31508CUX

290
HE40006BUE
HE40006BUX
HE40012BUI
PHCE2502EXC
PHCE3156
PHCE3156EXC
PHCE3159
PHCE340HK12
PHCE40012
PHCE4006
PHCE4009EXC
PHCE50015
PHCE5006
PHE12020
PHE2412
PHE3612
PHE4812
PHE4820
PHE6312
PHE7220
PHE7512
PHE9620
PHCE340HK9N
References Voltage (V) Rated current (A) Power (kW)
HCE240HK162

3x400

8,7

6
HCE240HK6X2

3x400

8,7

6
HCE250HK1122

3x400

17,3

9
HCE250HK12X2

3x400

17,3

9
HCE260HK1142

3x400

20,2

14
HCE260HK14X2

3x400

20,2

14
HCE270HK1212

3x400

30,3

21
HCE270HK212

3x400

30,3

21
HCE270HK21X2

3x400

30,3

21
HCE280HK146

3x400

66,3

46
HCE280HK146D

3x400

66,3

46
HCE280HK46X

3x400

66,3

46
HCE280HK46XD

3x400

66,3

46
HCE340HK6X

3x400

8,7

6
HCE500X800U15

3x400

21,7

15
HCE500X800U15X

3x400

21,7

15
HCE500X800U15XN

3x400

21,7

15
HCE500X800U24

3x400

34,6

24
HCE500X800U24X

3x400

34,6

24
HCE500X800U9

3x400

13

9
HCE500X800U9X

3x400

13

9
HE05X0809BUE

3x400

13

9
HE05X0809BUX

3x400

13

9
HE05X0815BUE

3x400

22

15
HE05X0815BUX

3x400

22

15
HE05X0824BUE

3x400

34,6

24
HE05X0824BUX

3x400

34,6

24
HE31504BUE

3x400

5,6

3,9
HE31504BUX

3x400

5,6

3,9
HE31504CUE

3x400

5,8

4
HE31504CUX

3x400

5,8

4
HE31508BUE

3x400

11,5

8
HE31508BUX

3x400

11,5

8
HE31508CUE

3x400

11,5

8
HE31508CUX

3x400

11,5

8
HE40006BUE

3x400

8,7

6
HE40006BUX

3x400

8,7

6
HE40012BUI

3x400

17,3

12
PHCE2502EXC

1x230

8,7

2
PHCE3156

3x400

8,7

6
PHCE3156EXC

3x400

8,7

6
PHCE3159

3x400

13

9
PHCE340HK12

3x400

17,3

12
PHCE40012

3x400

17,3

12
PHCE4006

3x400

8,7

6
PHCE4009EXC

3x400

13

9
PHCE50015

3x400

21,7

15
PHCE5006

3x400

8,7

6
PHE12020

3x400

17,3

12
PHE2412

3x400

34,6

24
PHE3612

3x400

52

36
PHE4812

3x400

69,3

48
PHE4820

3x400

69,3

48
PHE6312

3x400

90,1

63
PHE7220

3x400

103,9

72
PHE7512

3x400

108,3

75
PHE9620

3x400

138,6

96
PHCE340HK9N

3x400

13

9
