CW500 I (insulated)

CCW round

CW500 is an insulated cold water coil for VEX160, spigot diameter 500 mm.

Technical data
Data for CW5004L(R)OIC
Test pressure  3000 kPa
Max. operating pressure  1600 kPa
Number of rows of pipes  qty. 4
Number of circuits qty. 17
Spigot, diameter 500 mm
Pipe connection  DN32 (1¼")
Fin spacing 2.5 mm
Weight, insulated model (without fluid) 135 kg
Water content 8.3 l.

Dimensioned drawings

Dimensioned drawings CW500 insulated (L/R)

CW500 Left, insulated

CW500 insulated


CW500 Right, insulated

CW500 insulated




Add all about the product series CW500 I (insulated)
