Electric heating coil (HE)

HE heating coil is an accessory for the VEX4000 series and is used to increase the temperature of the supply air



Function and application

The coil is used to increase the supply air temperature and works by supply air passing over the electrically heated heating elements in the coil. The supply air absorbs the heat from the heating elements and thus achieves a higher temperature.

The coil can either be controlled by the EXcon control system or supplied for connection to a third-party control system.

Operation

To achieve the best basis for operation of each unit, calculations should always be carried out with EXselectPRO
Technical data

Technical data for duct-mounted coils

 Data for coils for VEX4010   HE1  HE2 HE3
 Power rating 4 kW 7 kW 14 kW
 min. airflow 1050 m³/h 1050 m³/h
1050 m³/h
Modulating steps 1 1 1
Weight 23 kg 24 kg 29 kg
 Data for coils for VEX4020   HE1  HE2 HE3
 Power rating 7 kW 11 kW 21 kW
 min. airflow 1500 m³/h 1500 m³/h
1500 m³/h
Modulating steps 1 1 1
Weight 27 kg 29 kg 34 kg
Data for coils for VEX4030   HE1  HE2 HE3
 Power rating 10 kW 15 kW 30 kW
 min. airflow 2000 m³/h 2000 m³/h
2000 m³/h
Modulating steps 1 1 2
Weight 32 kg 37 kg 44 kg
Data for coils for VEX4040   HE1  HE2 HE3
 Power rating 13 kW 20 kW 38 kW
 min. airflow 3000 m³/h 3000 m³/h
3000 m³/h
Modulating steps 1 1 2
Weight 35 kg 41 kg 50 kg
Data for coils for VEX4050   HE1  HE2 HE3
 Power rating 17 kW 24 kW 50 kW
 min. airflow 4000 m³/h 4000 m³/h
4000 m³/h
Modulating steps 1 1 2
Weight 38 kg 42 kg 57 kg
Data for coils for VEX4060   HE1  HE2 HE3
 Power rating 17 kW 33 kW 55 kW
 min. airflow 4820 m³/h 4820 m³/h
4820 m³/h
Modulating steps 1 2 2
Weight 41 kg 52 kg 62 kg
 Data for coils til VEX4070   HE1  HE2 HE3
 Power rating 20 kW 40 kW 60 kW
 min. airflow 6000 m³/h 6000 m³/h
6000 m³/h
Modulating steps 1 2 3
Weight 47 kg 56 kg 69 kg
Data for coils for VEX4080   HE1  HE2 HE3
 Power rating 25 kW 50 kW 75 kW
 min. airflow 7000 m³/h 7000 m³/h
7000 m³/h
Modulating steps 1 2 3
Weight 49 kg 65 kg 82 kg
Data for coils for VEX4090   HE1  HE2 HE3
 Power rating 33 kW 67 kW 100 kW
 min. airflow 8600 m³/h 8600 m³/h
8600 m³/h
Modulating steps 2 3 4
Weight 54 kg 82 kg 98 kg
Data for coils for VEX4100   HE1  HE2 HE3
 Power rating 42 kW 83 kW 125 kW
 min. airflow 10800 m³/h 10800 m³/h
10800 m³/h
Modulating steps 2 4 5
Weight 58 kg 87 kg 123 kg

Dimensions, dimensions table for section with a coil

Section with a built-in coil

Dimensions table

VEX4000 model ½ Height/Height  Length   Depth
VEX4010 [mm] 702/1309 480  1055
VEX4020 [mm]
702/1309 480 1275
VEX4030 [mm] 797/1499 480  1549
VEX4040 [mm]
847/1599 480  1630
VEX4050 [mm]
919/1744 480  1755
VEX4060 [mm]
1077/2069 480  1930
VEX4070 [mm]  1077/2069 480 2115
VEX4080 [mm]
1209/2494 480  2325
VEX4090 [mm]
1334/2744 480  2625
VEX4100 [mm]
1474/3024 480 2895

The indicated dimensions are the dimensions for the section - use EXselectPRO to get the correct dimensions for the whole air handling unit, including assembly fittings and seals.


Dimensions, dimensions table for section with two coils

Section with two built-in coils

Dimensions table

VEX4000 model ½ Height/Height  Length   Depth
VEX4010 [mm] 702/1309 1404  1055
VEX4020 [mm]
702/1309 1404 1275
VEX4030 [mm] 797/1499 1404  1549
VEX4040 [mm]
847/1599 1404  1630
VEX4050 [mm]
919/1744 1404  1755
VEX4060 [mm]
1077/2069 1404  1930
VEX4070 [mm]  1077/2069 1404 2115
VEX4080 [mm]
1209/2494 1404  2325
VEX4090 [mm]
1334/2744 1404 2625
VEX4100 [mm]
1474/3024 1404 2895

The indicated dimensions are the dimensions for the section - use EXselectPRO to get the correct dimensions for the whole air handling unit, including assembly fittings and seals.
